Knowledge transfer among multiple networks using their outputs or intermediate activations have evolved through extensive manual design from a simple teacher-student approach (knowledge distillation) to a bidirectional cohort one (deep mutual learning). The key factors of such knowledge transfer involve the network size, the number of networks, the transfer direction, and the design of the loss function. However, because these factors are enormous when combined and become intricately entangled, the methods of conventional knowledge transfer have explored only limited combinations. In this paper, we propose a new graph-based approach for more flexible and diverse combinations of knowledge transfer. To achieve the knowledge transfer, we propose a novel graph representation called knowledge transfer graph that provides a unified view of the knowledge transfer and has the potential to represent diverse knowledge transfer patterns. We also propose four gate functions that are introduced into loss functions. The four gates, which control the gradient, can deliver diverse combinations of knowledge transfer. Searching the graph structure enables us to discover more effective knowledge transfer methods than a manually designed one. Experimental results on the CIFAR-10, -100, and Tiny-ImageNet datasets show that the proposed method achieved significant performance improvements and was able to find remarkable graph structures.
