Background: Deep learning (DL)-based head and neck lymph node level (HN_LNL) autodelineation is of high relevance to radiotherapy research and clinical treatment planning but still underinvestigated in academic literature. Methods: An expert-delineated cohort of 35 planning CTs was used for training of an nnU-net 3D-fullres/2D-ensemble model for autosegmentation of 20 different HN_LNL. A second cohort acquired at the same institution later in time served as the test set (n=20). In a completely blinded evaluation, 3 clinical experts rated the quality of DL autosegmentations in a head-to-head comparison with expert-created contours. For a subgroup of 10 cases, intraobserver variability was compared to the average DL autosegmentation accuracy on the original and recontoured set of expert segmentations. A postprocessing step to adjust craniocaudal boundaries of level autosegmentations to the CT slice plane was introduced and the effect on geometric accuracy and expert rating was investigated. Results: Blinded expert ratings for DL segmentations and expert-created contours were not significantly different. DL segmentations with slice plane adjustment were rated numerically higher (mean, 81.0 vs. 79.6,p=0.185) and DL segmentations without slice plane adjustment were rated numerically lower (77.2 vs. 79.6,p=0.167) than manually drawn contours. DL segmentations with CT slice plane adjustment were rated significantly better than DL contours without slice plane adjustment (81.0 vs. 77.2,p=0.004). Geometric accuracy of DL segmentations was not different from intraobserver variability (mean, 0.76 vs. 0.77, p=0.307). Conclusions: We show that a nnU-net 3D-fullres/2D-ensemble model can be used for highly accurate autodelineation of HN_LNL using only a limited training dataset that is ideally suited for large-scale standardized autodelineation of HN_LNL in the research setting.
