Automated floor plan generation has recently gained momentum with several methods that have been proposed. The CVAAD Floor Plan Auto-Completion workshop challenge introduced MSD, a new dataset that includes existing structural walls of the building as an additional input constraint. This technical report presents an approach for extending a recent work, HouseDiffusion (arXiv:2211.13287 [cs.CV]), to the MSD dataset. The adaption involves modifying the model's transformer layers to condition on a set of wall lines. The report introduces a pre-processing pipeline to extract wall lines from the binary mask of the building structure provided as input. Additionally, it was found that a data processing procedure that simplifies all room polygons to rectangles leads to better performance. This indicates that future work should explore better representations of variable-length polygons in diffusion models. The code will be made available at a later date.
