Multi-modal time series analysis has recently emerged as a prominent research area in data mining, driven by the increasing availability of diverse data modalities, such as text, images, and structured tabular data from real-world sources. However, effective analysis of multi-modal time series is hindered by data heterogeneity, modality gap, misalignment, and inherent noise. Recent advancements in multi-modal time series methods have exploited the multi-modal context via cross-modal interactions based on deep learning methods, significantly enhancing various downstream tasks. In this tutorial and survey, we present a systematic and up-to-date overview of multi-modal time series datasets and methods. We first state the existing challenges of multi-modal time series analysis and our motivations, with a brief introduction of preliminaries. Then, we summarize the general pipeline and categorize existing methods through a unified cross-modal interaction framework encompassing fusion, alignment, and transference at different levels (\textit{i.e.}, input, intermediate, output), where key concepts and ideas are highlighted. We also discuss the real-world applications of multi-modal analysis for both standard and spatial time series, tailored to general and specific domains. Finally, we discuss future research directions to help practitioners explore and exploit multi-modal time series. The up-to-date resources are provided in the GitHub repository:this https URL
View on arXiv@article{jiang2025_2503.13709,
title={ Multi-modal Time Series Analysis: A Tutorial and Survey },
author={ Yushan Jiang and Kanghui Ning and Zijie Pan and Xuyang Shen and Jingchao Ni and Wenchao Yu and Anderson Schneider and Haifeng Chen and Yuriy Nevmyvaka and Dongjin Song },
journal={arXiv preprint arXiv:2503.13709},
year={ 2025 }
}
