GenEDA: Towards Generative Netlist Functional Reasoning via Cross-Modal Circuit Encoder-Decoder Alignment

The success of foundation AI has motivated the research of circuit foundation models, which are customized to assist the integrated circuit (IC) design process. However, existing pre-trained circuit foundation models are typically limited to standalone encoders for predictive tasks or decoders for generative tasks. These two model types are developed independently, operate on different circuit modalities, and reside in separate latent spaces. This restricts their ability to complement each other for more advanced capabilities. In this work, we present GenEDA, the first framework that cross-modally aligns circuit encoders with decoders within a shared latent space. GenEDA bridges the gap between graph-based circuit representation learning and text-based large language models (LLMs), enabling communication between their respective latent spaces. To achieve the alignment, we propose two paradigms to support both open-source trainable LLMs and commercial frozen LLMs. We leverage this aligned architecture to develop the first generative foundation model for netlists, unleashing LLMs' generative reasoning capability on the low-level and bit-blasted netlists. GenEDA enables three unprecedented generative netlist functional reasoning tasks, where it reversely generates high-level functionalities such as specifications and RTL code from low-level netlists. These tasks move beyond traditional gate function classification to direct generation of full-circuit functionality. Experiments demonstrate that GenEDA significantly boosts advanced LLMs' (e.g., GPT and DeepSeek series) performance in all tasks.
