An Efficient LiDAR-Camera Fusion Network for Multi-Class 3D Dynamic Object Detection and Trajectory Prediction

Service mobile robots are often required to avoid dynamic objects while performing their tasks, but they usually have only limited computational resources. To further advance the practical application of service robots in complex dynamic environments, we propose an efficient multi-modal framework for 3D object detection and trajectory prediction, which synergistically integrates LiDAR and camera inputs to achieve real-time perception of pedestrians, vehicles, and riders in 3Dthis http URLframework incorporates two novel models: 1) a Unified modality detector with Mamba and Transformer (UniMT) for object detection, which achieves high-accuracy object detection with fast inference speed, and 2) a Reference Trajectory-based Multi-Class Transformer (RTMCT) for efficient and diverse trajectory prediction of multi-class objects with flexible-length trajectories. Evaluations on the CODa benchmark demonstrate that our method outperforms existing ones in both detection (+3.71\% in mAP) and trajectory prediction (-0.408m in minADE$_5$ of pedestrians) metrics. Furthermore, on the challenging nuScenes detection benchmark, our detection model achieves competitive performance among LiDAR-camera fusion methods, with a mAP of 72.7\% and NDS of 75.3\%. Remarkably, the system demonstrates exceptional generalizability and practical deployment potential. When transferred and implemented on a wheelchair robot with an entry-level NVIDIA RTX 3060 GPU, it achieves real-time inference at 13.9 frames per second (FPS) with satisfactory accuracy. To facilitate reproducibility and practical deployment, we release the related code of the method at \href{this https URL}{this https URL\_Perception} and its ROS inference version at \href{this https URL}{this https URL\_packages}.
