The security of printed circuit boards (PCBs) has become increasingly vital as supply chain vulnerabilities, including tampering, present significant risks to electronic systems. While detecting tampering on a PCB is the first step for verification, forensics is also needed to identify the modified component. One non-invasive and reliable PCB tamper detection technique with global coverage is the impedance characterization of a PCB's power delivery network (PDN). However, it is an open question whether one can use the two-dimensional impedance signatures for forensics purposes. In this work, we introduce a novel PCB forensics approach using explainable AI (XAI) on impedance signatures. Through extensive experiments, we replicate various PCB tamper events, generating a dataset used to develop an XAI algorithm capable of not only detecting tampering but also explaining why the algorithm makes a decision about whether a tamper event has happened. At the core of our XAI algorithm is a random forest classifier with an accuracy of 96.7%, sufficient to explain the algorithm's decisions. To understand the behavior of the classifier in the decision-making process, we utilized SHAP values as an XAI tool to determine which frequency component influences the classifier's decision for a particular class the most. This approach enhances detection capabilities as well as advancing the verifier's ability to reverse-engineer and analyze two-dimensional impedance signatures for forensics.
View on arXiv@article{safa2025_2506.05734,
title={ There's Waldo: PCB Tamper Forensic Analysis using Explainable AI on Impedance Signatures },
author={ Maryam Saadat Safa and Seyedmohammad Nouraniboosjin and Fatemeh Ganji and Shahin Tajik },
journal={arXiv preprint arXiv:2506.05734},
year={ 2025 }
}
